Home | Case study | Wigan Council – High-Rise Fire Safety Retrofit

High-Rise Fire Safety Retrofit Programme

Sector

Social Housing

Location

North West

Service

Active Fire

The project saw Fieldway pioneering an enhanced approach to high-rise fire safety, combining specialist systems and coordinated delivery across occupied buildings to achieve full compliance with the new building regulations.

The programme brought together a range of fire safety upgrades, including an enhanced PA and Communication System, fire alarms, automatic opening vents (AOVs), emergency lighting and fire compartmentation.

Fieldway also coordinated with specialist design consultants to upgrade the cold-water systems.

What we did

Fieldway delivered a fire safety retrofit programme across seven occupied high-rise residential blocks containing 700+ flats at Scholes Village, Wigan.

Specifications

  • Fire alarm and detection systems
  • Smoke and heat detectors
  • Visual Alarm Devices (VADs)
  • Fire compartmentation
  • Automatic Opening Vents (AOVs)
  • Emergency lighting with MyMesh monitoring
  • Boosted and mains cold-water systems
  • Fire-rated cabling and containment
  • System testing, commissioning and integration

Project Overview

Contract Value

£4

M

Programme Duration

14

Months

Flats

700

+

High rise blocks

7

Resident access rate

99.6

%

Social value spend

£

600

k

The system enables live speech and pre-recorded evacuation messages to be broadcast to individual floors or multiple floors, helping emergency services communicate instructions to residents in a targeted way.

The installation includes:

Wall-mounted speakers: Metal cabinet speakers in each flat lobby, with additional speakers in communal and landlord circulation areas.

Floor-by-floor control: Distribution network amplifier panels serve up to four floors, with a dedicated amplifier module and two loudspeaker circuits for each floor.

Ground-floor master control: A master amplifier and control panel includes programmable switches for pre-recorded evacuation messages and a microphone for live announcements by the Fire and Rescue Service.

Two-way emergency communication: Type C combined fire telephone and disabled refuge outstations on each stair landing allow residents to communicate directly with the master panel.

Visual alerts: Visual Alarm Devices (VADs) form part of the installation.

Fire-resistant cabling: Fire-rated cables support the power supplies to the master panel and system amplifiers.

The Emergency Voice Communication System (EVCS) also includes robust, vandal-resistant phones in the stairwells on each floor.

Together, these features provide a dedicated communication network to support emergency announcements and two-way communication during an incident.

Innovations

Enhanced PA and Communication System gives Fire and Rescue Service greater control over emergency announcements.

Definitely worth a look, the improvements would definitely make our lives easier in the event of a confirmed high-rise fire at any of the blocks.

Wigan Community Fire and Ambulance Station

Fieldway has been the best. They were always punctual, and the quality of the work was brilliant.

Tenants

Scholes Village

Enhanced PA System Specifications

  • Floor-specific and multi-floor evacuation announcements
  • Pre-recorded evacuation messages
  • Manual emergency announcements via master microphone
  • Wall-mounted speakers in lobbies and communal areas
  • Distribution amplifier panels serving up to four floors
  • Dedicated amplifier module for each floor
  • Two loudspeaker circuits per floor
  • Ground-floor master amplifier and control panel
  • Emergency Voice Communication System (EVCS)

Fieldway installed and programmed Automatic Opening Vents (AOVs) to support everyday ventilation as well as smoke control during an emergency.
The AOVs are programmed to open at specific times each day, improving ventilation across the floors and helping promote healthier air quality for residents.

The system also recognises rainfall and automatically closes the vents to prevent rainwater entering the buildings, reducing the risk of damp and water pooling.

During a fire, the AOVs open to help draw smoke out of the buildings, improving air quality and visibility within communal areas.

Additionally, we  increased the number of smoke and heat detectors across communal and residential areas in all seven blocks. This provides wider fire detection coverage and improves the ability to identify potential incidents.

The enhanced detection coverage, evacuation communication and smoke ventilation systems work together to support the building’s wider fire safety arrangements.

Benefits

Enhanced detection coverage, evacuation communication and smoke ventilation systems.

Fieldway used a floor-by-floor approach and prioritised communal areas to maintain building access.

We prioritised communal-area works, including emergency lighting and stairwell AOV upgrades, to ensure safe access for residents while works progressed.

A dedicated on-site team, including a Project Manager, Site Manager and Tenant Liaison Officer, provided a constant presence within Scholes Village, keeping residents informed well in advance of works commencing,  and helping the team achieve a 99.6% access rate.

Resident Care and Communication

Working within occupied high-rise buildings required a carefully phased approach to maintain resident safety and comfort throughout the programme.
